If you’ve ever wanted to run a local AI assistant or chatbot with a beautiful web interface on your own machine, you’re not alone. Tools like Ollama (for running open-source LLMs) and Open WebUI (a beautiful chat frontend) make this surprisingly accessible.

In this ariticle, I will walk you through a clean Terraform configuration that deploys both services in Docker containers with support for CPU-only systems and optional NVIDIA GPU acceleration.

The Architecture at a Glance

• Ollama: Runs the language model (e.g., llama3, qwen, mistral) and exposes an API on port 11434.
• Open WebUI: A user-friendly web app that connects to Ollama’s API, served on port 3000.
• Both containers live on a shared Docker network (ollama-network) so they can talk to each other using container names (http://ollama:11434).
• Persistent data is stored in Docker volumes:
• ollama_data: Caches downloaded models.
• open_webui_data: Saves conversations, settings, and user data.

The Terraform Setup (CPU-First)

Here’s the core of our main.tf:

terraform {
  required_providers {
    docker = {
      source  = "kreuzwerker/docker"
      version = "~> 3.6"
    }
  }
}

provider "docker" {}

resource "docker_network" "ollama_net" {
  name   = "ollama-network"
  driver = "bridge"
}

resource "docker_volume" "ollama_data" {
  name = "ollama_data"
  lifecycle {
    prevent_destroy = true  # Don’t accidentally wipe your models!
  }
}

resource "docker_volume" "open_webui_data" {
  name = "open_webui_data"
}

resource "docker_container" "ollama" {
  name  = "ollama"
  image = "ollama/ollama:latest"

  ports {
    external = 11434
    internal = 11434
  }

  env = [
    "OLLAMA_HOST=0.0.0.0",
    "OLLAMA_ORIGINS=*",
    "OLLAMA_MAX_LOADED_MODELS=1",  # One model at a time (saves RAM)
    "OLLAMA_KEEP_ALIVE=15m",
    "OLLAMA_NOPRUNE=true"
  ]

  networks_advanced {
    name = docker_network.ollama_net.name
  }

  volumes {
    volume_name    = docker_volume.ollama_data.name
    container_path = "/root/.ollama"
  }

  memory = 8589934592  # ~8 GB RAM
  restart = "unless-stopped"
}

resource "docker_container" "open_webui" {
  name  = "open-webui"
  image = "ghcr.io/open-webui/open-webui:main"

  networks_advanced {
    name = docker_network.ollama_net.name
  }

  volumes {
    volume_name    = docker_volume.open_webui_data.name
    container_path = "/app/backend/data"
  }

  env = [
    "OLLAMA_BASE_URL=http://ollama:11434",
    "WEBUI_HOST=0.0.0.0",
    "WEBUI_PORT=8080"
  ]

  ports {
    internal = 8080
    external = 3000
  }

  memory = 2147483648  # ~2 GB RAM
  restart = "unless-stopped"
  depends_on = [docker_container.ollama]
}

Apply it with:

terraform init
terraform plan
terraform apply

Then visit http://localhost:3000

Why You Need Volumes?

Containers are ephemeral by nature. Means if you stop or remove a container, everything inside it goes away. Here, your downloaded models (which can be 6-8GB each, sometimes more) and chat history would disappear. By mounting Docker volumes:

• /root/.ollama: ollama_data: Persists models across runs.
• /app/backend/data: open_webui_data: Keeps your UI settings and conversations.

The prevent_destroy = true on ollama_data is a safety measure: it stops Terraform from deleting the volume even if you destroy the stack (unless you explicitly override it). Smart for expensive-to-download assets! you can manually delete it with docker volume rm ollama_data

Adding NVIDIA GPU Support (Optional)

By default, this setup uses your CPU. But if you have an NVIDIA GPU and want faster inference, you can enable GPU access with the NVIDIA Container Toolkit.

Step 1: Install the Conatainer Toolkit

Follow the official guide:
https://docs.nvidia.com/datacenter/cloud-native/container-toolkit/latest/install-guide.html

On Ubuntu, it is usually:

curl -fsSL https://nvidia.github.io/libnvidia-container/gpgkey | sudo gpg --dearmor -o /usr/share/keyrings/nvidia-container-toolkit-keyring.gpg
curl -s -L https://nvidia.github.io/libnvidia-container/stable/deb/nvidia-container-toolkit.list | \
  sed 's#deb https://#deb [signed-by=/usr/share/keyrings/nvidia-container-toolkit-keyring.gpg] https://#g' | \
  sudo tee /etc/apt/sources.list.d/nvidia-container-toolkit.list
sudo apt update && sudo apt install -y nvidia-container-toolkit
sudo nvidia-ctk runtime configure --runtime=docker
sudo systemctl restart docker

Step 2: Adjust Your Terraform

Add the gpu block in the Ollama container:

resource "docker_container" "ollama" {
  # ... existing config ...

  # Enable all GPUs
  gpu {
    mode = "all"
  }

  # Optional: fine-tune CPU affinity
  # cpu_set = "0-3"  # Use cores 0 through 3
}

Now you can run terraform apply again.

Note: The gpu block requires Docker provider v3.6+ and a Docker daemon configured with NVIDIA runtime.

Now Ollama will leverage your GPU for inference, often 2–5x faster than CPU, depending on your model and hardware.

Security & Tuning Tips

• Don’t expose Ollama publicly: It has no auth by default. Keep port 11434 bound to localhost unless behind a reverse proxy with auth.
• Limit models: OLLAMA_MAX_LOADED_MODELS=1 prevents memory overload on smaller systems.
• Adjust RAM: If you have less than 8 GB free, reduce memory (but expect swapping or *CRASHES* with larger models).

Try It Yourself

This setup works on: - Linux (with Docker + optional NVIDIA toolkit) - macOS (Docker Desktop CPU only, no GPU) - Windows (WSL2 + Docker Desktop CPU only)

Final Thoughts

Local LLMs are no longer just for researchers or cloud budgets. With Ollama, Open WebUI, and a bit of Terraform magic, you can have a responsive, private, and fully controllable AI assistant running on your own hardware, whether it’s a Raspberry Pi (okay, maybe not… yet) or a gaming rig with an RTX 4090.

And because everything is defined as code, sharing or recreating your setup is as easy as terraform apply.

Happy prompting! 🦙✨
